Description
This product is a closed precision optical fiber laser cutting machine developed for the jewelry and handicraft gift industry, which can cut a variety of metal plates,
Pipe material is mainly suitable for the rapid cutting of carbon steel, silicon steel, stainless steel, titanium alloy, galvanized sheet, pickled sheet and other metal materials.
Using international advanced technology, low operating cost, good cutting quality, and high processing efficiency, it is an ideal model for the small-format metal material processing industry.
Superiority:
◆Superior beam quality: smaller focused spot, higher work efficiency and high processing quality;
◆Higher cutting speed: 2 times of the same power CO2 laser cutting machine;
◆Higher stability: using fiber laser, stable performance, long service life of key components;
◆Higher electro-optical conversion efficiency: The optical conversion efficiency of fiber laser cutting machine is 3 times higher than that of CO2 laser cutting machine, which is energy-saving and environmentally friendly;
◆Lower operating cost: The power consumption of the whole machine is only 20-30% of that of similar CO2 laser cutting machines;
◆Lower maintenance cost: optical fiber transmission, no need for reflective lenses, can save a lot of maintenance costs;
◆The product is easy to operate and maintain: optical fiber transmission, no need to adjust the optical path;
◆Super flexible light guide effect: small size, compact structure, easy to flexible processing requirements.
Scope of application
Technical Parameters
Technical Parameters:
Laser output power 500W Laser wavelength 1060nm
Laser medium YVO4 beam quality <0.373mrad
X axis maximum stroke 300mm Maximum idle speed 50m/min
Y axis maximum stroke 500mm minimum line width ≤0.15mm
Z axis maximum stroke 50-70mm Maximum carbon steel cutting thickness 6mm (high quality cutting 0.5-5mm)
Maximum cutting range (XY axis) 300mm×500 mm Maximum stainless steel cutting thickness 4mm (high-quality cutting 0.5-3mm)
Repeated positioning accuracy of worktable ≤±0.03mm/m Power supply requirement 380V/50HZ
