cnc rebar shear line introduction
cnc rebar shear line
Product introduction of automatic CNC steel bar cutting line: This equipment can cut high-strength ribbed steel bars of 1, 2, 3, and 4 levels, and integrates the centralized cutting, conveying and storage of straight bars. The self-developed steel bar cutting software (patented) is suitable for the shearing of multi-item steel bars and can improve the material utilization rate; up to 6-level material preparation station can store a large amount of materials; two-way rewinding mechanism increases the storage capacity of finished products. Times. "Customers can choose to use an automatic inclined pulling feeding device, which improves production efficiency in all directions, and personnel do not directly touch the steel bars, reducing the intensity of manual work."
Design feature description of automatic CNC steel bar cutting line:
1. Each part adopts an adjustable footboard design, which can be adapted to different heights of ground and adjusted individually.
2. The feeding motor adopts frequency conversion to start, which reduces the vibration when the motor is started; when the steel bars are aligned, the speed is gradually reduced to reduce the impact force between the steel bars and the baffle, which can be more effectively aligned.
3. Using hydraulic cylinder to drive shearing, features: light weight and small size under the same shearing force; transmission depends on the continuous flow of oil. The oil has the ability to absorb vibration, and a hydraulic buffer device is set in the oil circuit. Therefore, unlike the mechanical mechanism, processing and assembly errors will cause vibration and impact, which makes the transmission very stable and facilitates frequent reversing.
4. The hydraulic cylinder is used to compress the steel bar, and with a guide column, the compression force is large, and it is flat to ensure the stability when cutting the steel bar.
5. The small angle design of hydraulic scissors reduces the lateral force that the frame bears during shearing and improves the service life; the scissors fixing frame is rigid enough and has good integrity; the guide adopts flexible materials and is equipped with an adjustment structure, which can effectively prevent Impact on the scissors holder when there is an obstruction point.
6. Before the hydraulic shears, there is a scissor roller table. The end close to the scissors is equipped with two air cylinders to control the lifting of the roller table. When the steel bar is cut, it can move synchronously with the hydraulic cylinder to ensure that the steel feed end is in the cutting process. Will not deform.
7. After cutting, the roller table is driven by a screw lifting motor as a whole, which is fast and convenient to adjust the size.
8. After shearing, the roller discharge bar is divided into three sections, which can meet the needs of independent work, coordinated work, and simultaneous work according to different steel bar lengths, which can save air consumption and improve response speed.
9. The raw materials of the whole machine are shot blasted, sandblasted, primer, and topcoat through large shot blasting machine equipment, which greatly extends the service life of the equipment.
Advantages of automatic CNC steel bar cutting line:
CNC steel bar cutting production line: It can be widely used in construction, highway, high-speed rail, tunnel, water conservancy, power plant, nuclear power plant and other industries. It is suitable for continuous cutting of steel bars of various specifications and different lengths. Cut and sort.
Intelligent operation and modular input are not required for the quality of operators.
Servo motor has fixed length, high precision, and the precision of cutting length can reach ±2mm.
The hydraulic shear system has high pressure, long life and low failure rate.
The three-level storage tank makes it easier to classify steel bars after shearing.
Modular combination of vertical steel bending center, horizontal steel bending center, etc. Achieve seamless connection of processes.
The finished product has small processing error and low material loss. Reduce material costs.
