Description
Serial Number |
product name |
unit |
detailed parameters |
1 |
Beam length |
mm |
2200 |
2 |
Rail length |
mm |
3500(can customize) |
3 |
Lateral (X-direction) effective travel |
mm |
1500 |
4 |
Longitudinal (Y-direction) effective travel |
mm |
3000(can customize) |
6 |
Flame Clash |
set |
1 |
8 |
Flame cutting thickness |
mm |
≤150mm |
9 |
Cutting speed |
mm/min |
0-3500 |
10 |
Airspeed |
mm/min |
4000 |
11 |
Applicable gas types |
- |
Acetylene, Propylene |
12 |
Cutting graphics |
- |
Capable of creating cutting lines and arcs Any flat shaped part |
13 |
Work interface |
- |
All Chinese/All English |
14 |
control system |
set |
Shanghai Jiaotong University |
16 |
Nesting software |
set |
FASTCAM |
